Jilong 280E Fusion Splicer, All-Rounder, Middle Trunk Line

Jilong 280E Fusion Splicer – Best Price in Bangladesh (2025) | High-Performance Fiber Splicing Machine
Hot-Selling, All-Rounder Middle Trunk Line Fusion Splicer
The Jilong 280E Fusion Splicer is a high-precision, all-rounder fiber splicing machine designed for middle trunk line and FTTx networks. Its advanced splicing technology, fast operation, and lightweight design make it the perfect tool for fiber optic professionals, field technicians, and engineers.

Key Features
Active Clad-Alignment Technology – Ensures high-precision splicing with minimal splice loss
Ultra-Fast Splicing & Heating – 6-second splicing & 18-second heating for maximum efficiency
Lightweight & Portable Design – Weighs only 1.9kg (with battery) – Ideal for field & aerial work
4.3-inch High-Resolution Color Display – 800x480 pixel screen for clear fiber viewing & operation
Powerful 6800mAh Battery – Supports 300+ splicing & heating cycles per charge
Automatic Fiber & ARC Identification – Smart technology for error-free splicing
Large Data Storage – Saves 10,000 splice records & 2,000 images
Wide Fiber Compatibility – Supports SM, MM, DS, NZDS, and G.657 fiber types
Durable & Rugged – Designed for harsh environments, dust-proof, and water-resistant

Jilong 280E Fusion Splicer Technical Specifications
Alignment Method: Active Clad-Alignment
Applicable Fiber Types: SM (G.652/G.657), MM (G.651), DS (G.653), NZDS (G.655)
Compatible Fiber/Cable: 0.25~3.0mm, Leather Cable
Fiber Cleave Length: 8-16mm
Splicing Mode: 128 programmable modes
Splicing Time: 6 sec. (SM G652 Quick Mode)
Heating Time: 18 sec. (Adjustable, Quick Mode)
Splice Loss: SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dB
Return Loss: >60dB
Electrode Life: 5,000 arcs (replaceable)
Battery: 6800mAh, supports 300+ splicing & heating cycles per charge
Storage Capacity: 10,000 splice records, 2,000 images
Tension Test: 1.96~2.25N
Operating Condition: Altitude: 0~5,000m, -20°C to +50°C, Max Wind Speed: 15m/s
Weight: 1.6kg (without battery), 1.9kg (with battery)
Display: 4.3-inch high-resolution (800x480) color touchscreen
USB 2.0 Port – For firmware updates & data transfer


Why Choose the Jilong 280E Fusion Splicer?
Perfect for FTTx, FTTH, and Middle Trunk Line Networks
Fast & Efficient Splicing – Saves Time & Boosts Productivity
Lightweight & Durable – Ideal for Field & Aerial Operations
Designed for Harsh Environments – Built to Last
Best Price in Bangladesh (2025) – Unbeatable Value
